Humminbird Ice Helix 7 Chirp Sonar / GPS G4 Combo All-Season Fish Finder

Item No.: 199531

This item can only ship to the 48 contiguous United States.

This item is out of stock for the season. Please check back in October.

Product Details

Product Details

The Humminbird ICE HELIX 7 CHIRP Sonar / GPS G4 Combo All-Season Fish Finder includes everything you need to learn where the fish are under the ice and the open water. With the Dual-Spectrum CHIRP Sonar with 3/4-inch target separation and CHIRP Interference Rejection, you'll see high-resolution images on both the flasher and traditional 2D sonar views. A built-in GPS with Humminbird Basemap includes charts of more than 10,000 lakes, and you can expand that as the GPS G4 All-Season Combo is already compatible with both LakeMaster and Navionics maps. AutoChart Live ICE, Jig Charge Mode, split-screen views, a premium shuttle, and a 15 Ah lithium battery are features specifically designed for the ice angler. When the ice thaws, the HELIX 7 All-Season Fish Finder is ready right from the box for your boat or any other portable applications. You'll see it all on the full-color, seven-inch HD LCD display all year round with a Humminbird ICE HELIX 7 CHIRP Sonar / GPS G4 Combo All-Season Fish Finder.

  • CHIRP Digital Sonar
    • CHIRP stands for “Compressed High-Intensity Radar Pulse.” By covering a wide range of frequencies, CHIRP produces more accurate, more detailed returns of fish, structure, and the bottom.
  • Dual-Spectrum CHIRP Sonar
    • See high-resolution returns of individual fish, bait, and structure on both the flasher and traditional 2D sonar views at greater depths and range, with target separation down to 3/4 in.
  • CHIRP Interference Rejection
    • Six settings keep competing sonar signals from cluttering your screen, providing a clear view in both sonar and flasher modes.
  • Adjustable Sonar Zoom
    • Allows anglers to hone in on fish, whether they are tight to the bottom or suspended high in the water column. Utilize 2X zoom on the flasher screen or up to 16X zoom on 2D sonar view.
  • Internal Precision GPS Built-In
    • Take the guesswork out of finding your fishing spot. Pinpoint your location by marking waypoints of your most productive areas and navigate out to your spot and back safely with GPS tracks.
  • Humminbird Basemap Built-In
    • Enhanced standard Basemap provides you with a clear view of underwater terrain and surrounding points of interest so you can fish and navigate with total confidence. Identify buoys, daymarkers, hazards, marinas, contours, depth markers, and much, much more. Includes charts of more than 10,000 lakes.
  • AutoChart Live ICE
    • Create real-time 1-foot contour maps of your fishing spots to find fish faster. Create maps on ice to show humps and drop-offs or entire reefs while utilizing Humminbird LakeMaster features, Depth Highlight, Shallow Water Highlight, and Water Level Offset.
  • Micro SD Card Reader
    • Single card reader slot used for premium mapping, software updates, or to save screenshots, sonar recordings, and waypoints from your ICE HELIX.
  • Ultra-Bright and Detailed LCD Display
    • The ICE HELIX screen provides everything you need to know on a crystal-clear display with adjustable brightness. Whether in a fish house or on open ice, you'll easily be able to see digital depth display, sonar returns, and more exclusive features, all shown in real-time.
  • Jig Charge Mode
    • Use your ICE HELIX to charge up your glow-painted spoons and jigs and get back down to the hot bite quickly.
  • Premium Shuttle
    • It has it all. Master power switch, quick-connect SAE power cables, large handle, multiple 1/4 in. - 20 mounting options for accessories, two rod holders, cable and transducer management, and a battery cover.
  • All-Season Ready
    • This ICE HELIX fish finder comes with everything you need to use on both ice and on your boat or portable applications in the summer.
  • Specifications:
    • Item Number: 411760-1
    • Series: ICE
    • Display Size Diagonal: 7 in.
    • Display Pixel Matrix: 1024 H x 600 V
    • Sonar Standard: Dual-Spectrum CHIRP
    • Sonar Coverage: 15° and 21° at -3dB
    • Sonar Optional: 50 kHz, 50/Low Airmar CHIRP
    • CHIRP Frequencies Supported: 50/200 (28 - 75 / 130 - 250 kHz), 83/200 (75 - 155 / 130 - 250 kHz), Full Mode (150 - 220 kHz), Narrow Mode (180 - 240 kHz), and Wide Mode (140 - 200 kHz)
    • Sonar Frequencies Supported: 50/80/200 kHz
    • Depth Sonar: 400 ft.
    • Interface: Keypad Control
    • Features: Dual-Spectrum CHIRP, Interference Rejection, Jig Charge Mode, Portable, Built-In GPS, Built-In Mapping, AutoChart Live ICE, and MEGA Live Imaging
    • Memory Card Slot: Single Micro SD
    • Compatible with: AIS and AutoPilot
    • Power Draw: 800 mA
    • Power Input: 10.8 - 20 VDC
    • Power Output Peak-to-Peak: 4000 W
    • Power Output RMS: 500 W
    • Screen Snap Shot: Included
    • Sonar Recording: Included
    • Mount Standard: Portable
    • Transducer Mount Location: Portable
    • GPS Chartplotting: Included
    • GPS Trackplotting: Included
    • LakeMaster Compatibility: Yes
    • CoastMaster Compatibility: Yes
    • Navionics Gold/HotMaps Compatibility: Yes
    • Navionics Platinum+ Compatibility: Yes
    • Platinum Compatibility: Yes
    • Heading Sensor GPS Compatibility: Yes
    • Upgradable Software: Yes
    • View Preset Keys: No
    • X-Press Menu System: Yes
    • Custom Digital Readout: Yes
    • Custom View Selections: Yes
    • Display Colors Grayscale: 16-Bit
    • Display Size: 5 - 7 in.
    • Speed: Included
    • Temperature: Built-In
    • Temperature Alarm: Yes
    • Temperature Graph: No
    • Transducer Included: XI 9 1521
    • HDMI Compatible: No
    • MEGA Live Compatibility: No
    • UPC: 0082324056758
  • Manufacturer's one-year limited warranty
  • Qty. per Pack:
    • ICE HELIX 7 CHIRP GPS G4 fish finder
    • Dual-Spectrum CHIRP ICE transducer
    • 15 Ah lithium battery with 2 USB ports and battery life indicator
    • Charger
    • ICE shuttle
    • Hardware
    • Quick-connect SAE power cables
    • Silicone screen cover
    • All necessary accessories to use on a boat or in portable applications (transom mount CHIRP transducer with optional suction cup transducer mount, fish finder gimbal mount, and power cord)

Please note: Once opened, the product cannot be returned, and if defective or damaged, it must be returned to the manufacturer for warranty repair or replacement.
