The Garmin ECHOMAP UHD2 73sv/PS22-IF Ice Bundle gives ice anglers a clear, real-time look beneath the ice with advanced LiveVü Forward and LiveVü Down sonar views. The 7-inch ECHOMAP UHD2 touchscreen chartplotter with keyed assist displays fish and structure in sharp detail, helping you stay on active schools of walleye, perch, and crappie. It includes the Panoptix PS22-IF transducer and preloaded Garmin Navionics+ maps featuring over 23,000 U.S. lakes with a one-year subscription for daily updates. Easily create custom combos that merge sonar and mapping data, swap between wide and narrow sonar beams with the removable lens, and transport it all in the rugged, glove-friendly carrying case built for long days on the ice.

• Part #: 010-02684-30
• 7” ECHOMAP UHD2 touchscreen chartplotter with keyed assist
• Panoptix PS22-IF transducer with LiveVü Forward and Down sonar
• Create custom combo pages that display sonar and mapping together, and switch between wide and narrow beams with the removable transducer lens
• Rugged, glove-friendly portable carrying case with removable transducer lens
• Manufacturer's limited warranty
• General:
  • Dimensions: 10.5" × 9.5" × 10.5" (26.7 × 22.9 × 26.7 cm)
  • Weight: 12.2 lbs (5.5 kg)
  • Water rating: IPX7
  • Touchscreen: Yes
  • Display Type: WVGA, TN
  • Display Size: 6.1" x 3.4", 7.0" (15.5 x 8.7, 17.8 cm)
  • Display resolution: 800 x 480 pixels
  • Input: Touchscreen with Keyed Assist
• Maps & Memory:
  • Accepts Data Cards: 1 microSD card 32 GB maximum size
  • Waypoints: 5000
  • Track points: 50,000
  • Tracks: 50 saved tracks
  • Navigation Routes: 100
• Ice Fishing Details:
  • Battery type and size: SLA, 7Ah
  • Bag size: S
  • Included transducer: PS22-IF
  • Transducer holding feature: Pole-free transducer rotation system
• Sensors:
  • GPS: Yes
  • GLONASS: Yes
  • Galileo: Yes
  • Beidou: Yes
  • Has built-in receiver: Yes
  • Receiver: 10 Hz
  • NMEA 2000 Compatible: Yes
  • Supports WAAS: Yes
  • Supports multi-band, multi-constellation GPS: Yes
• Built-in Maps:
  • Built-in Auto Guidance+: Yes (downloadable via ActiveCaptain app)
  • Garmin Navionics+ Inland & Coastal: Yes
  • Garmin Navionics+ (Inland): Yes
• Optional Map Support:
  • Garmin Navionics+: Yes
  • Garmin Navionics Vision+: Yes
  • TOPO 100K: Yes
  • Standard Mapping: Yes
  • Garmin Quickdraw Contours: Yes
• Chartplotter Features:
  • ActiveCaptain compatible: Yes
• Electrical Features:
  • Power Input: 9 to 18 Vdc
• Sonar Features:
  • Displays sonar: Yes
  • Power output: 500 W
  • Traditional sonar (dual frequency/beam): Built-in (single channel CHIRP, 50/77/83/200 kHz, L, M, H CHIRP)
  • ClearVü: Built-in 260/455/800/1000/1200 kHz
  • SideVü:Built-in 260/455/800/1000/1200 kHz
  • Panoptix sonar: Yes
  • LiveScope: Yes
• Connections:
  • NMEA 2000 ports: 1
  • Garmin Marine Network Ports: 1
  • 12-pin transducer ports: 1
  • Bluetooth pairing: Yes (BLE)
  • ANT (Connectivity): Yes
  • Garmin Wi-Fi network (local connection): Yes
• In the Box:
  • ECHOMAP UHD2 73sv or 75sv touchscreen with keyed assist chartplotter
  • Mapping: Garmin Navionics+ for U.S. inland or Canada inland and coastal
  • Panoptix PS22-IF transducer
  • Transducer rotator
  • Transducer bracket
  • PS22-IF removable lens
  • Rechargeable battery
  • Charger
  • Small bag, base and handle
  • Power cable
  • Foam float
  • Hardware
  • Documentation
• Manufacturer's one-year warranty
