The Garmin STRIKER 4 Portable Fish Finder with Dual-Beam Transducer helps anglers locate fish with ease and precision. Its 3.5-inch color display and built-in high-sensitivity GPS allow you to mark and revisit your favorite fishing spots, docks, and ramps. The included CHIRP (77/200 kHz) sonar transducer offers detailed and clear images, while the sonar history rewind feature enables you to scroll back through images to mark missed waypoints. Smooth Scaling graphics ensure uninterrupted imagery when switching between depth ranges, and the device also features a built-in flasher and speed data display, making it essential for your fishing expedition.

• Easy-to-use 3.5 in. color fishfinder with built-in, high sensitivity GPS
• Find fish - mark and return to hot spots, docks, and ramps
• Convenient keypad operation
• Includes CHIRP (77/200 kHz) sonar transducer; transmit power (200 W RMS)/(1,600 W peak-to-peak)
• Upgrade to high-performance CHIRP with GT8 or GT15 transducer (each sold separately)
• Manufacturer's one-year warranty
• Includes:
  • STRIKER 4
  • Dual-beam transducer
  • Transom and trolling motor mounts
  • Tilt/swivel mount
  • Power cable
  • Documentation
• Technical Specifications:
  • Part #: 010-01550-00
  • Physical Dimensions: 3.6 in. x 5.9 in. x 1.6 in.
  • Display Size: 1.9 in x 2.9 in., 3.5 in. diagonal
  • Display Resolution: 480 x 320 pixels
  • Display Type: HVGA color
  • Weight 8.1 oz.
  • Water Rating: IPX7
  • Mounting Options: flush, tilt/swivel
  • Transducer Cable Length: 20 ft.
  • Waypoints/Favorites/Locations: 5,000
  • Track Points: 50,000
  • Tracks: 50
  • Navigation Routes: 100
  • Integrated GPS
  • Dual-Frequency (50/200 kHz) Sonar Capable
  • Dual-Beam (77/200 kHz) Sonar Capable
  • Frequencies Supported: Traditional 50/77/200 kHz and CHIRP (mid and high)
  • Bottom Lock - shows return from the bottom up
  • Water Temperature Sensor Included
  • 4-Pin Transducer Ports: 1
  • Power Input: 10 to 20 Vdc
  • Current draw at 12 V: 0.23 A
  • Max Current Draw: 1.0 A
  • Power Consumption: 2.8
  • Transmit Power: 200 W (RMS)
  • Maximum Depth*: 1,600 ft. freshwater, 750 ft. saltwater
  • Water Temperature Log and Graph
  • Split-Screen Zoom
  • Ultrascroll - displays fish targets at higher boat speeds
  • Fish Symbol ID - helps identify fish targets
  • Autogain Technology - minimizes clutter, maximizes targets
  • Adjustable Depth Line - measure the depth of underwater objects
  • A-Scope - real-time display of fish passing through the transducer beam
  • Mark waypoints
  • COG - Course over Ground
  • *Depth capacity is dependent on the water bottom type and other water conditions
