Garmin GPSMAP 1042xsv Chartplotter/Fishfinder

Item#: F24338

Model:

The Garmin GPSMAP 1042xsv Chartplotter/Fishfinder delivers powerful navigation and fishfinding performance, designed for serious anglers and mariners who demand precision and simplicity. This advanced chartplotter combines a vivid 10” color display with an intuitive keypad interface, user-programmable keys, and a multifunction control knob for seamless operation, even in rough conditions. Enjoy unparalleled clarity with wide viewing angles and brilliant screen resolution, making it easy to read your charts and sonar data. Compatible with premium Garmin maps and charts, this unit ensures you always have the most detailed navigation tools at your fingertips. Garmin Marine Network support enables you to share data across multiple units, while built-in sonar capabilities help you identify fish, structure, and the underwater environment with exceptional accuracy. This is the ultimate tool for making the most of your time on the water, whether you're navigating open seas or pinpointing fish-holding hotspots.

General
- Dimensions: 12.5" x 7.3" x 2.7" (31.8 x 18.5 x 6.9 cm)
- Weight: 4.1 lbs (1.85 kg)
- Water rating: IPX7
- Display Type: WSVGA, TN
- Display Size: 8.8" x 4.9"; 10.1" diagonal (22.4 x 12.5 cm; 25.7 cm diagonal)
- Display resolution: 1024 x 600 pixels
- Mounting Options: Bail or flush
- Input: Keyed
Maps & Memory
- Accepts Data Cards: 2 SD cards
- Waypoints: 5000
- Track points: 50,000
- Tracks: 50 saved tracks
- Navigation Routes: 100
Sensors
- GPS: Yes
- GLONASS: Yes
- Built-in receiver: Yes
- Receiver: 10 Hz
- NMEA 2000 Compatible: Yes
- NMEA 0183 Compatible: Yes
- Supports WAAS: Yes
Built-in Maps
- Built-in Auto Guidance+: Yes
- Garmin Navionics+ Inland & Coastal: Yes
- Tide tables: Yes
Optional Map Support
- Garmin Navionics+™: Yes
- Garmin Navionics Vision+™: Yes
- TOPO 100K: Yes
- Standard Mapping: Yes
- Garmin Quickdraw Contours: Yes
- Raster chart support: Yes
Chartplotter Features
- Smart Mode Compatible: Yes
- AIS: Yes
- DSC: Yes
- Fusion-Link™ compatible radios: Yes
- GSD Black Box Sonar Support: Yes
- GCV Black Box Sonar Support: Yes
- ActiveCaptain® compatible: Yes
- GRID (Garmin Remote Input Device) compatible: Yes
- Wireless Remote Compatible: Yes
- Sailing Features: Yes
Electrical Features
- Power Input: 10 to 32 Vdc
- Typical current draw at 12 Vdc: 1.9 A
- Maximum current draw at 12 Vdc: 2.7 A
- Maximum power usage at 10 Vdc: 32.4W
Sonar Features
- Displays sonar: Yes
- Power output: 1 kW
- Traditional sonar: Yes (single channel CHIRP, 70/83/200 kHz, L, M, H CHIRP)
- ClearVü: Yes with CHIRP (built-in)
- SideVü: Yes with CHIRP (built-in)
- Panoptix™ sonar: Yes
- LiveScope: Yes
Connections
- NMEA 2000® ports: 1
- NMEA 0183 Input (Rx) Ports: 1
- NMEA 0183 output (Tx) ports: 1
- Video input ports: 1 (BNC composite)
- Garmin Marine Network Ports: 2
- 12-pin transducer ports: 1
- BLUETOOTH® pairing: Yes
- ANT+ (Connectivity): Yes
- Garmin Wi-Fi network (local connection): Yes
In the Box With Transducer
- Part # 010-01740-60
- GPSMAP 1042xsv chartplotter
- GT52HW-TM transducer
- Power/data cable
- NMEA 2000 T-connector
- NMEA 2000 drop cable (2 m)
- Transducer
- Bail mount kit with knobs
- Flush mount kit with gasket
- Protective cover
- Trim piece snap covers
- Documentation
In the Box Without Transducer
- Part # 010-01740-50
- GPSMAP 1042xsv chartplotter
- Power/data cable
- NMEA 2000 T-connector
- NMEA 2000 drop cable (2 m)
- 8-pin transducer to 12-pin sounder adapter cable
- Bail mount kit with knobs
- Flush mount kit with gasket
- Protective cover
- Trim piece snap covers
- Documentation
Manufacturer's one-year limited warranty
