Garmin ECHOMAP Ultra 2 166sv 16 in. Chartplotter

Item#: F25197

Includes Transducer:

No Transducer

GT56UHD-TM Transducer

Product Details

The Garmin ECHOMAP Ultra 2 166sv 16 in. Chartplotter provides anglers with an ultra-clear view of structure, cover, and fish, featuring a full 16-inch HD touchscreen with keyed-assist functionality and high-performance sonar capabilities. Available with or without transducer, the GT56UHD-TM (Part # 010-03386-01) transducer offers CHIRP, ClearVü, and SideVü scanning sonar capabilities. Additionally, full Panoptix LiveScope compatibility enables real-time forward and downward imaging, allowing for precise targeting in schools or pinpointing isolated targets. Whether mapping a highland reservoir's structure or targeting fish along a weed line, Garmin Navionics+ mapping with Auto Guidance+ technology helps you plot your course with precision. HDMI output supports screen sharing with a second display at the helm, and Bluetooth enables hands-free voice control.

The Garmin ECHOMAP Ultra 2 166sv 6 in. Chartplotter supports wireless networking to share sonar, routes, and waypoints with other ECHOMAP Ultra 2 or UHD2 units on board—ideal for large boats running multiple stations. Multiband GPS provides enhanced position accuracy even in challenging environments, giving you the confidence to mark key structures or drop on precise waypoints. Whether you’re live-scoping suspended crappie, scanning flats for bass, or marking offshore walleye structure, the Ultra 2 offers a full package for anglers who rely on accurate data and high-definition visibility.

16 in. keyed-assist HD touchscreen with HDMI output and Bluetooth
GT56UHD-TM (Part # 010-03386-01) transducer with CHIRP, ClearVü, SideVü, and LiveScope support included in option with the transducer
Includes Garmin Navionics+ mapping with Auto Guidance+
Wireless networking and multiband GPS for advanced system integration
Manufacturer's two-year limited warranty
General:
- Dimensions: 16.9" x 10.5" x 3.14" (43.0 x 26.6 x 8.0 cm)
- Weight: 9.5 lbs (4.31 kg)
- Water rating: IPX7
- Touchscreen: Yes
- Type: FHD, IPS
- Size: 13.6" x 7.7"; 15.6" diagonal (34.5 x 19.5 cm; 39.7 cm diagonal)
- Resolution: 1920 x 1080 pixels
- Mounting Options: Bail or flush
- Input: Touchscreen with Keyed Assist
Maps & Memory
- Accepts Data Cards: 2 microSD cards
- Waypoints: 5000
- Track Points: 50,000
- Tracks: 50 saved tracks
- Navigation Routes: 100
Sensors
- GPS: Yes
- GLONASS: Yes
- Galileo: Yes
- Built-in Receiver: Yes
- Receiver: 10 Hz
- NMEA 2000 Compatible: Yes
- NMEA 0183 Compatible: Yes
- Supports WAAS: Yes
- Supports Multi-band, Multi-constellation GPS: Yes
Built-in Maps
- Auto Guidance+: Yes
- Garmin Navionics+ Inland & Coastal: Yes
- Tide Tables: Yes
Optional Map Support
- BlueChart g3: Yes
- BlueChart g3 Vision: Yes
- LakeVü g3: Yes
- LakeVü g3 Ultra: Yes
- Garmin Navionics+: Yes
- Garmin Navionics Vision+: Yes
- TOPO 100K: Yes
- Standard Mapping: Yes
- Garmin Quickdraw Contours: Yes
Chartplotter Features
- AIS: Yes
- DSC: Yes
- Fusion-Link Compatible: Yes
- ActiveCaptain Compatible: Yes
- Supports Voice Commands: Yes
- Sailing Features: Yes
Electrical Features
- Power Input: 9 to 18 Vdc
- Typical Current Draw @ 12 Vdc: 3.9 A
- Max Current Draw @ 12 Vdc: 6.6 A
- Max Power Usage @ 10 Vdc: 48W
Sonar Features
- Displays Sonar: Yes
- Power Output: 600 W
- Traditional Sonar: Built-in (single channel CHIRP, 70/83/200 kHz, L, M, H CHIRP)
- ClearVü: Built-in 260/455/800/1000/1200 kHz
- SideVü: Built-in 260/455/800/1000/1200 kHz
- Panoptix: Yes
- LiveScope: Yes
Connections
- NMEA 2000 Ports: 1
- Video Output: 1 HDMI
- Garmin Marine Network Ports: 2 (large connector)
- 12-Pin Transducer Ports: 12-pin scanning sonar
- Bluetooth Pairing: Yes
- ANT+ Connectivity: Yes
- Garmin Wi-Fi Network: Yes
In the Box (With Transducer)
- Part # 010-03386-01
- ECHOMAP Ultra 166sv with optional Garmin Navionics+
- GT56UHD-TM transducer
- Power cable
- Bail mount kit with knobs
- Protective sun cover
- Trim caps
- Hardware
- Documentation
In the Box (Without Transducer)
- Part # 010-03386-00
- ECHOMAP Ultra 166sv with optional Garmin Navionics+
- Power cable
- Bail mount kit with knobs
- Protective sun cover
- Trim caps
- 8-pin transducer to 12-pin sounder adapter cable
- Hardware
- Documentation
